Rod Ram Machine Features:Highly innovative; Save time and money; Intelligent and easy-to-use; Fully automatic systems; Rod Dia Range Min – Max Dia:4mm – 500 mm; Production Per Hour in Kg:7-10+; Long- life, with modern technology and optimized design; Ram Machine ensures precision both in the pressing procedure and in the sinter zone; Temperature controls are also provided.
Sunkoo Rod Extruder (Teflon PTFE Rod extrusion) is designed using latest technology, fully reliable and easy to operate for customers. Performance in terms of production and working hour capacity is competitive to other machines. Low maintenance is required , giving high production in market.
Ram extrusion is a process enabling the continuous production and processing of PTFE (Polytetrafluoroethylene). The basic material is PTFE powder. The powder is fed into a cylindrical extrusion pipe, compressed by means of a ram and at the same time, transported through the pipe, which is heated up to sintering temperature.
| Model No. | PFB-150 |
| Screw | Single-Plunger |
| Control System | Computerize automatic controlled |
| Electricity Consumption | 2.5kw/h |
| Tolerance OD(mm) | 0.1-0.5 |
| Tolerance TH(mm) | +0.1 |
| Length | Unlimited |
| Min – Max Dia | 4-600mm |
| Heating | 4 -6 zones |
| Plastic Extruder | PTFE Rod |
| Compressive force | 100-600kN |
| PTFE | PTFE or Recycle PTFE material. |
| Floor area of the Machine | 1.6 M2 |
| Production Per Hour | Extrusion at 9-18kg/h |
| Voltage/PH/Hz | AC380V 50Hz 3 Phase |
| High of the Machine (mm) | 2580mm |
| Weight | 1320 kg |
